- 【HIOKI】POWER ANALYZER PW8001
8 Inputs Channels that Provide World Class Flexibility and Accuracy
DC, 0.1 Hz to 5 MHz, 3-phase 4-wire,
High Precision for Motor and Inverter Efficiency Analysis
• Capture the slightest power loss with a wideband power measurement of world-class accuracy
• Reliable reproduction of input waveforms with 15 MHz sampling and 18-bit resolution
• Multi-circuit measurement of up to 8 channels of power data with a single instrument
• Automatic sensor identification and phase compensation for more accurate and error-free measurements
• Simultaneously analyze 4 motors with a single instrument
• Link two PW8001 units to double the number of channels via optical link
POWER ANALYZER
Model:
PW8001
Maker:
HIOKI
Feature
- World-class measurement accuracy
- Accurate capture of power fluctuations
- U7005 15 MS/s INPUT UNIT
- Up to 8 power channels optimizing your measurement
- PMSM online parameter measurement (*2)
- Compensation of torque meter measurement error (*2)
- Safe evaluation of increasingly high-voltage power condit
- Analysis of power loss in reactors
