- KANOMAX High Temperature Anemometer – 6162 Series
Test airflow in high temperature conditions up to 932°F
Request a Quote
The Kanomax 6162 Series High Temperature Anemometer is engineered for precise measurements in extreme heat. Ideal for applications such as drying process control, maintaining airflow in forming processes, exhaust air management, and device performance testing. It features interchangeable probes, optional accessories, and complies with ISO 13579 and NFPA 86 standards, ensuring efficiency in various industries.
*Excludes sales to WA, OR, CA, NV, MT, ID, WY, UT, and MI.
Feature
- Simultaneous measurement of air velocity and temperature up to 500℃ (932°F)
- Two probes selections, Middle Temperature up to 200℃ (392°F) and High Temperature up to 500℃ (932°F)
- Temperature compensation circuitry ensures accurate velocity measurements in rapidly fluctuating air stream temperatures
- RS232C interface, analog output and remote control terminal equipped
- Store up to 999 measurements
- Simultaneous display of air velocity and temperature
- Secondary temperature compensation circuit provides quick response time
- Standard with a NIST traceable calibration certificate*
- Graphic display allows easy review of historical data
- 6162 allows you to easily interchange smart probes
Applications
- Drying process control
- Forming process control
- Exhaust air measurement
- Device performance testing
- ISO 13579 energy efficiency testing
- NFPA 86 testing for industrial ovens
Kanomax High Temperature Anemometer 6162 Series
Specifications
| Main Unit Specifications | |
|---|---|
| General Specifications | |
| Analog Output | DC 0 to 1V |
| Interface | RS-232C/printer |
| Input | Remote start/stop function |
| Datalogging | Store up to 999 measurements |
| Power Supply | 6 × 1.5 V C cells / AC adapter (100 to 240 V) |
| Operating Environment | |
| Main Unit | 41 – 104 ºF (5 – 40 ºC) |
| Storage Environment | 14 to 122°F (-10 to 50°C) with no condensation |
| Dimensions | |
| Main Unit | 8.7″ x 5.9″ x 3.3″ (220 x 150 x 85mm) |
| Weight | 3.9 lbs (1.8kg) |
| What’s Included | Meter, operation manual, AC adapter, analog output cable (2pc), shoulder strap, C-batteries (6 qty) |
| Warranty | 1 year |
| Probe Specifications | |||
|---|---|---|---|
| Model | 0203 | 0204 | |
| Temperature Range | |||
| Air Velocity Measuring Range | 32 to 212°F | 40 to 9840 fpm (0.2 to 50.0 m/s) | |
| 212 to 392°F | 80 to 9840 fpm (0.4 to 50.0 m/s) | ||
| 392 to 572°F | n/a | 138 to 9840 fpm (0.7 to 50.0 m/s) | |
| 572 to 752°F | n/a | 197 to 9840 fpm (1.0 to 50.0 m/s) | |
| Accuracy | +/- 3% of reading | ||
| Temperature Measuring Range | 32 to 392°F (0 to 200°C) | 32 to 932°F (0 to 500°C) | |
| Accuracy | +/- 1% of reading | ||
| General Specifications | |||
| Dimensions / Weight | Ø 11 x 200mm (Ø 0.4″ x 7.8″), 0.4 lbs (200 g) | Ø 14 x 1000mm (Ø 0.6″ x 39.4″)1.1 lbs (500 g) | |
| Probe Cables | Teflon Coating | ||
| Heat-resistance | 392°F (200°C) | ||
| Extension Cable | Vinyl Coating | ||
| Heat-resistance | 176°F (80°C) | ||
