Monitoring Board SVP-01-U(Previous model# SVM-03)
This board can be connected with a camera module by using a SerDes board or a connection-board. Power supply to the SVP-01-U board is via USB 3.0 connector. Without a computer, a USB-AC adapter can be used instead. This board can output the signals to HDMI monitors or UVC (USB3.0 / PC).
In addition, the multi-boot function allows for various functions such as side by side image output with simultaneous input of two sensors and synchronized input using multiple SVP-01-U boards. This board adopt UVC as PC driver, so supports not only the Windows environment but also the LINUX environment.
By using Monitoring Board SVP-01-U by Net Vision, customers are developing and debugging the monitoring image into the ECU while viewing live images taken by the camera.
Monitoring Board
Model:
SVP-01-U(Previous model# SVM-03)
Maker:
NetVision Co., Ltd.
Uses
- Camera Modules
- Output of CMOS sensor images to HDMI monitor,
- Around View Development
- Simultaneous Monitoring of Multiple Sensors
