EMIC Transportation Vibration Testing

Transport Testing System FT-02K/100: Comprehensive Vibration Testing

The FT-02K/100, is a versatile transport packaging testing system designed to meet a wide range of transport test standards, including ASTM D4169-16 and ISTA 3A for truck transport at low vibration frequencies around 1Hz. This system covers a broad frequency range from 1Hz to 300Hz, making it suitable for various testing scenarios.

Transport Testing System

Model:

FT-02K/100

Maker:

EMIC CORPORATION

Features

• Low-Frequency Testing: Capable of performing low-frequency random transport tests starting from 1Hz.

• Cost-Effective: Significantly reduces installation costs compared to medium and large displacement devices.

• Energy Efficient: Utilizes permanent magnets for energy savings.

• Compact Design: Space-efficient design allows for flexible installation in various locations.



Video

Specifications

Model FT-02K/100
Maximum Excitation Force 2000 N
Frequency Range 1 to 300 Hz
Shaker Table Size 500 × 500 mm
Load Capacity Up to 60 kg
Weight 262 kg
Power Supply 3-phase AC 200V, 50/60Hz
