Bench-type optical power meter suitable for R&D and production of optical disks
Bench-type optical power meter suitable for R&D and production of optical disksBench-type optical power meter suitable for R&D and production of optical disks
Maker:
ADCMT
Feature
Applicability table for the nine product types of sensors
Shape | Part Number | Wavelength Range | Calibration Wavelength |
Power Range | Light Receiving Area | |
General-purpose | Thin | 82311B | 390 to 1100 nm | 780 nm | 1 nW to 50 mW | Approx. 9.5 mm × 9.5 mm |
Cylinder | 82321B | 390 to 1100 nm | 780 nm | 1 nW to 50 mW | Approx. 8.5 mmφ | |
High-power | Thin | 82313B | 390 to 1100 nm | 650 nm | 10 nW to 200 mW | Approx. 8.5 mmφ |
Cylinder | 82323B | 390 to 1100 nm | 650 nm | 10 nW to 200 mW | Approx. 8.5 mmφ | |
Blue-violet | Thin | 82312B | 390 to 450 nm | 405 nm | 10 nW to 100 mW | Approx. 10 mm×10 mm |
Cylinder | 82322B | 390 to 450 nm | 405 nm | 10 nW to 100 mW | Approx. 8.5 mmφ | |
Three-wavelength | Thin | 82314B | 390 to 900 nm | 405 nm | 10 nW to 100 mW | Approx. 10 mm×10 mm |
Thin and large | 82314BW | 390 to 900 nm | 405 nm | 10 nW to 100 mW | Approx. 18 mm×18 mm | |
Cylinder | 82324B | 390 to 900 nm | 405 nm | 10 nW to 100 mW | Approx. 8.5 mmφ |
